HD6413002F12V データシート

Name: HD6413002F12V
Brand: RENESAS
SKU: 180115373-0000-0000-0000

HD6413002F12V - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD6413002F12V の詳細情報

型番	HD6413002F12V
メーカー	RENESAS
データシート
ADC Channels	YES
Address Bus Width	24
Bit Size	16
Clock Frequency-Max	12 MHz
DAC Channels	NO
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	S-PQFP-G100
JESD-609 Code	e6
Length	14 mm
Moisture Sensitivity Level	3
Number of I/O Lines	46
Number of Terminals	100
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	NO
Package Body Material	PLASTIC/EPOXY
Package Code	FQFP
Package Shape	SQUARE
Package Style	FLATPACK, FINE PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	3.05 mm
Speed	12 rpm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	Tin/Bismuth (Sn/Bi)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	20
Width	14 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
