HD6412324SVTE25 データシート

Name: HD6412324SVTE25
Brand: RENESAS
SKU: 180064701-0000-0000-0000

HD6412324SVTE25 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD6412324SVTE25 の詳細情報

型番	HD6412324SVTE25
メーカー	RENESAS
データシート
ADC Channels	YES
Additional Feature	ALSO OPERATES AT 2.7V MINIMUM SUPPLY AT 20MHZ
Address Bus Width	24
Bit Size	16
Clock Frequency-Max	25 MHz
DAC Channels	YES
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	S-PQFP-G120
Length	14 mm
Number of I/O Lines	95
Number of Terminals	120
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	TFQFP
Package Shape	SQUARE
Package Style	FLATPACK, THIN PROFILE, FINE PITCH Meter
Seated Height-Max	1.2 mm
Speed	25 rpm
Supply Voltage-Max	3.6 V
Supply Voltage-Min	2.7 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Form	GULL WING
Terminal Pitch	0.4 mm
Terminal Position	QUAD
Width	14 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
