HA17555F-EL-E データシート

Name: HA17555F-EL-E
Brand: RENESAS
SKU: 180143505-0000-0000-0000

HA17555F-EL-E - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HA17555F-EL-E の詳細情報

型番	HA17555F-EL-E
メーカー	RENESAS
データシート
Analog IC - Other Type	PULSE; RECTANGULAR
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	4.85 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	2.03 mm
Supply Voltage-Max (Vsup)	15 V
Supply Voltage-Min (Vsup)	5 V
Surface Mount	YES
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	4.4 mm
