HA17431PNA データシート

Name: HA17431PNA
Brand: RENESAS
SKU: 180064577-0000-0000-0000

HA17431PNA - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HA17431PNA の詳細情報

型番	HA17431PNA
メーカー	RENESAS
カテゴリ	レギュレータ
データシート
Analog IC - Other Type	TWO TERMINAL VOLTAGE REFERENCE
Category	Shunt Regulators
Ik(mA)max.	150
Ioff	1
JESD-30 Code	O-PBCY-T3
JESD-609 Code	e0
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.15 A
Output Voltage-Max	2.55 V
Output Voltage-Min	2.44 V
Output Voltage-Nom	2.495 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-92
Package Equivalence Code	SIP3,.1,50
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Pt(W)	-
Qualification Status	Not Qualified
Sub Category	Voltage References
Surface Mount	NO
Technology	BIPOLAR
Temp Coef of Voltage-Max	64.892 ppm/Cel
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Copper (Sn/Cu)
Terminal Form	THROUGH-HOLE
Terminal Pitch	1.27 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Topa[Tjopa](degC)max.	85
Topa[Tjopa](degC)min.	-
Totalpowerdissipation(W)	500
Trim/Adjustable Output	NO V
VKA(V)	40
Vo(V)max.	-
Vref(V)typ.	2.495
ステータス	In Mass Production
ピン数	3
