2SD2163 データシート

Name: 2SD2163
Brand: RENESAS
SKU: 30119348-0000-0000-0000

2SD2163 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

NPN型バイポーラトランジスタ | 低周波用

2SD2163 の詳細情報

型番	2SD2163
メーカー	RENESAS
種別	バイポーラトランジスタ
データシート
Case Connection	ISOLATED
Collector Current-Max (IC)	10 A
Collector-emitter Voltage-Max	100 V
Configuration	DARLINGTON WITH BUILT-IN DIODE AND RESISTOR
DC Current Gain-Min (hFE)	1000
JESD-30 Code	R-PSFM-T3
JESD-609 Code	e0
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Peak Reflow Temperature (Cel)	225
Polarity/Channel Type	NPN
Power Dissipation-Max (Abs)	30 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	NO
Terminal Finish	TIN LEAD
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	10
Transistor Application	SWITCHING
Transistor Element Material	SILICON
