2SC3357-T1 データシート

Name: 2SC3357-T1
Brand: RENESAS
SKU: 30082515-0000-0000-0000

2SC3357-T1 - RENESAS の商品詳細ページです。

No Image

２営業日以内に回答いたします

NPN型バイポーラトランジスタ | 高周波用

2SC3357-T1 の詳細情報

型番	2SC3357-T1
メーカー	RENESAS
種別	バイポーラトランジスタ
データシート
Additional Feature	LOW NOISE
Case Connection	COLLECTOR
Collector Current-Max (IC)	0.1 A
Collector-base Capacitance-Max	1 pF
Collector-emitter Voltage-Max	12 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	50
Highest Frequency Band	ULTRA HIGH FREQUENCY BAND
JESD-30 Code	R-PSSO-F3
JESD-609 Code	e0
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	NPN
Power Dissipation Ambient-Max	2 W
Qualification Status	Not Qualified
Surface Mount	YES
Terminal Finish	Tin/Bismuth (Sn/Bi)
Terminal Form	FLAT
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	10
Transistor Application	AMPLIFIER
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	6500 MHz
