2SC2954 データシート

Name: 2SC2954
Brand: RENESAS
SKU: 30082360-0000-0000-0000

2SC2954 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

NPN型バイポーラトランジスタ | 高周波用

2SC2954 の詳細情報

型番	2SC2954
メーカー	RENESAS
種別	バイポーラトランジスタ
データシート
Additional Feature	LOW NOISE
Case Connection	COLLECTOR
Collector Current-Max (IC)	0.15 A
Collector-base Capacitance-Max	1.8 pF
Collector-emitter Voltage-Max	18 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	30
Highest Frequency Band	VERY HIGH FREQUENCY BAND
JESD-30 Code	R-PSSO-F3
JESD-609 Code	e0
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Polarity/Channel Type	NPN
Power Dissipation Ambient-Max	2 W
Power Dissipation-Max (Abs)	2 W
Power Gain-Min (Gp)	10 dB
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	FLAT
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	AMPLIFIER
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	3000 MHz
