RP1-12V データシート

Name: RP1-12V
Brand: PANASONIC
SKU: 280145964-0000-0000-0000

RP1-12V - PANASONIC の商品詳細ページです。

228時間24分後以内に見積もり依頼を頂ければ、
05月08日(水) 9:00 までに見積もり回答いたします。

検討リストに追加する

RP1-12V の詳細情報

型番	RP1-12V
メーカー	PANASONIC
データシート
Body Breadth	9 inch
Body Height	4 mm
Body Length or Diameter	10.6 mm
Coil Operate Voltage(DC)	9 V
Coil Power	140 mW
Coil Release Voltage(DC)	1.2 V
Coil Resistance	1028 ohm
Coil Voltage(DC)-Max	18 V
Coil Voltage-Nom	12 V
Coil/Input Supply Type	DC
Contact Current(DC)-Max	0.1 A
Contact DC Max Rating R Load	0.1A@30VDC
Contact Resistance	50 mohm
Contact Voltage(DC)-Max	30 V
Contact/Output Supply Type	DC
Dielectric Strength Between Coil and Contacts	1500 Vrms
Dielectric Strength Between Open Contacts	750 Vrms
Electrical Life	100000 Cycle(s)
End Contact Material	Silver
End Contact Plating	GOLD
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Manufacturer Series	RP
Number of Terminals	6
Operate Time	3 ms
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
PCB Hole Count	6
Physical Dimension	10.6mm x 9mm x 4mm
Relay Action	LATCHED
Relay Form	1 FORM C
Relay Function	SPDT
Relay Type	RF RELAY
Release Time	2 ms
Terminal Length	0.004 inch
Termination Type	SOLDER
Weight	1 g
