JQ1-5V データシート

Name: JQ1-5V
Brand: PANASONIC
SKU: 200011984-0000-0000-0000

JQ1-5V - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

JQ1-5V の詳細情報

型番	JQ1-5V
メーカー	PANASONIC
データシート
Additional Feature	RATINGS ARE AS PER NO AND NC RATING IS 2A/250VAC AND 2A/110VDC
Body Breadth	10 inch
Body Height	16 mm
Body Length or Diameter	20 mm
Coil Current(DC)-Max	0.08 A
Coil Operate Voltage(DC)	3.75 V
Coil Power	400 mW
Coil Release Voltage(DC)	0.25 V
Coil Resistance	62.5 ohm
Coil Voltage(DC)-Max	5 V
Coil Voltage-Nom	5 V
Coil/Input Supply Type	DC
Contact AC Max Power Rating R Load	625VA@250VAC
Contact AC Max Rating R Load	5A@250VAC
Contact Current(AC)-Max	5 A
Contact Current(DC)-Max	5 A
Contact DC Max Power Rating R Load	90W@110VDC
Contact DC Max Rating R Load	5A@110VDC
Contact Resistance	100 mohm
Contact Voltage(AC)-Max	250 V
Contact Voltage(DC)-Max	110 V
Contact/Output Supply Type	AC/DC
Electrical Life	50000 Cycle(s)
End Contact Material	Silver Alloy
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Mounting Feature	THROUGH HOLE-STRAIGHT MOUNT
Number of Terminals	5
Operate Time	5 ms
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
Packing Method	BOX
Physical Dimension	20mm x 10mm x 16mm
Reference Standard	CSA; SEMKO; TUV; UL; VDE
Relay Action	MOMENTARY
Relay Form	1 FORM C
Relay Function	SPDT
Relay Type	POWER/SIGNAL RELAY
Release Time	2 ms
Terminal Length	0.004 inch
Termination Type	SOLDER
