HEV2AN-P-DC24V データシート

Name: HEV2AN-P-DC24V
Brand: PANASONIC
SKU: 400058371-0000-0000-0000

HEV2AN-P-DC24V - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

HEV2AN-P-DC24V の詳細情報

型番	HEV2AN-P-DC24V
メーカー	PANASONIC
データシート
Body Breadth	41 inch
Body Height	39.4 mm
Body Length or Diameter	50 mm
Coil Current(DC)-Max	0.079 A
Coil Operate Voltage(DC)	16.8 V
Coil Power	1920 mW
Coil Release Voltage(DC)	1.2 V
Coil Resistance	300 ohm
Coil Voltage(DC)-Max	26.4 V
Coil Voltage-Nom	24 V
Coil/Input Supply Type	DC
Contact Current(DC)-Max	20 A
Contact DC Max Rating R Load	20A@800VDC
Contact Resistance	100 mohm
Contact Voltage(DC)-Max	1000 V
Contact/Output Supply Type	DC
Dielectric Strength Between Coil and Contacts	5000 Vrms
Dielectric Strength Between Open Contacts	2000 Vrms
Electrical Life	1000 Cycle(s)
End Contact Material	Silver Nickel
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Mounting Feature	THROUGH HOLE-STRAIGHT MOUNT
Number of Terminals	10
Operate Time	30 ms
Operating Temperature-Max	55 Cel
Operating Temperature-Min	-40 Cel
PCB Hole Count	10
Packing Method	BOX
Physical Dimension	50MM X 41MM X 39.4MM
Reference Standard	VDE
Relay Action	MOMENTARY
Relay Form	2 FORM A
Relay Function	DPST
Relay Type	POWER/SIGNAL RELAY
Release Time	10 ms
Terminal Length	0.0053 inch
Termination Type	SOLDER
Weight	120 g
