EXBV8VR000V データシート

Name: EXBV8VR000V
Brand: PANASONIC
SKU: 150001071-0000-0000-0000

EXBV8VR000V - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

EXBV8VR000V の詳細情報

型番	EXBV8VR000V
メーカー	PANASONIC
データシート
Additional Feature	RATED CURRENT: 1A
Construction	Rectangular
Element Power Dissipation	0.063 W
First Element Resistance	0 ohm
JESD-609 Code	e3
Mounting Feature	SURFACE MOUNT
Network Type	JUMPER
Number of Elements	1
Number of Functions	4
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Package Height	0.6 mm
Package Length	3.2 mm
Package Shape	RECTANGULAR PACKAGE
Package Style	SMT Meter
Package Width	1.6 mm
Packing Method	TR, PUNCHED, 7 INCH
Rated Temperature	70 Cel
Reference Standard	IEC60115-9
Resistance	0 ohm
Resistor Type	ARRAY/NETWORK RESISTOR
Second/Last Element Resistance	0 ohm
Size Code	0612
Sub Category	ARRAY/NETWORK RESISTOR
Technology	METAL GLAZE/THICK FILM
Terminal Finish	MATTE TIN OVER NICKEL
Terminal Shape	WRAPAROUND
