EEVFK2A331M データシート

Name: EEVFK2A331M
Brand: PANASONIC
SKU: 150029159-0000-0000-0000

EEVFK2A331M - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

EEVFK2A331M の詳細情報

型番	EEVFK2A331M
メーカー	PANASONIC
データシート
Capacitance	330 uF
Capacitor Type	ALUMINUM ELECTROLYTIC CAPACITOR
Diameter	18 mm
Dielectric Material	ALUMINUM (WET)
Height	16.5 mm
JESD-609 Code	e3
Leakage Current	0.33 mA
Length	19 mm
Mounting Feature	SURFACE MOUNT
Negative Tolerance	20 %
Number of Terminals	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Package Shape	CYLINDRICAL PACKAGE
Package Style	SMT Meter
Packing Method	TR, EMBOSSED, 13 INCH
Polarity	POLARIZED
Positive Tolerance	20 %
Rated DC Voltage (URdc)	100 V
Reference Standard	AEC-Q200
Ripple Current	687.75 mA
Size Code	7575
Tan Delta	0.07
Terminal Finish	TIN
Terminal Shape	FLAT
Width	19 mm
