EEU-FC1E121 の詳細情報

型番	EEU-FC1E121
メーカー	PANASONIC
データシート
Capacitance	120 uF
Capacitor Type	ALUMINUM ELECTROLYTIC CAPACITOR
Diameter	6.3 mm
Dielectric Material	ALUMINUM (WET)
JESD-609 Code	e3
Leakage Current	.03 mA
Length	15 mm
Manufacturer Series	FC
Mounting Feature	THROUGH HOLE MOUNT
Negative Tolerance	20 %
Number of Terminals	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Package Shape	CYLINDRICAL PACKAGE
Package Style	Radial Meter
Packing Method	TAPE
Polarity	POLARIZED
Positive Tolerance	20 %
Rated DC Voltage (URdc)	25 V
Reference Standard	AEC-Q200
Ripple Current	260 mA
Series	EEU-FC
Tan Delta	0.14
Terminal Finish	Tin (Sn)
Terminal Pitch	2.5 mm
Terminal Shape	WIRE
