EEEFK1H101GP

Name: EEEFK1H101GP
Brand: PANASONIC
SKU: 150026913-0000-0000-0000

EEEFK1H101GP - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

EEEFK1H101GP の詳細情報

型番	EEEFK1H101GP
メーカー	PANASONIC
種別	アルミ電解コンデンサ
Capacitance	100 uF
Capacitor Type	ALUMINUM ELECTROLYTIC CAPACITOR
Diameter	8 mm
Dielectric Material	ALUMINUM (WET)
Height	10.2 mm
Leakage Current	0.05 mA
Length	8.3 mm
Mounting Feature	SURFACE MOUNT
Negative Tolerance	20 %
Number of Terminals	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Package Shape	CYLINDRICAL PACKAGE
Package Style	SMT Meter
Packing Method	TR, EMBOSSED, 15 INCH
Polarity	POLARIZED
Positive Tolerance	20 %
Rated DC Voltage (URdc)	50 V
Reference Standard	AEC-Q200
Ripple Current	262.5 mA
Size Code	3333
Tan Delta	0.10
Terminal Shape	FLAT
Width	8.3 mm
