DSP2A-DC12V-R データシート

Name: DSP2A-DC12V-R
Brand: PANASONIC
SKU: 140071601-0000-0000-0000

DSP2A-DC12V-R - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DSP2A-DC12V-R の詳細情報

型番	DSP2A-DC12V-R
メーカー	PANASONIC
データシート
Body Breadth	11 inch
Body Height	10.5 mm
Body Length or Diameter	20.2 mm
Coil Operate Voltage(DC)	9.6 V
Coil Release Voltage(DC)	1.2 V
Coil Resistance	480 ohm
Coil Voltage(DC)-Max	15.6 V
Coil Voltage-Nom	12 V
Coil/Input Supply Type	DC
Contact AC Max Power Rating R Load	1250VA@250VAC
Contact AC Max Rating R Load	5A@250VAC
Contact Current(AC)-Max	5 A
Contact Current(DC)-Max	5 A
Contact DC Max Power Rating R Load	150W@125VDC
Contact DC Max Rating R Load	5A@125VDC
Contact Resistance	30 mohm
Contact Voltage(AC)-Max	250 V
Contact Voltage(DC)-Max	125 V
Contact/Output Supply Type	AC/DC
Dielectric Strength Between Coil and Contacts	3000 Vrms
Dielectric Strength Between Open Contacts	1000 Vrms
Electrical Life	100000 Cycle(s)
End Contact Material	Silver Tin Oxide
End Contact Plating	GOLD
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Number of Terminals	6
Operate Time	10 ms
Operating Temperature-Max	60 Cel
Operating Temperature-Min	-40 Cel
PCB Hole Count	6
Physical Dimension	20.2mm x 11mm x 10.5mm
Reference Standard	CSA; TUV; UL
Relay Action	LATCHED
Relay Form	2 FORM A
Relay Function	DPST
Relay Type	POWER/SIGNAL RELAY
Release Time	5 ms
Terminal Length	0.0035 inch
Termination Type	SOLDER
Weight	4.5 g
