DRA2124E データシート

Name: DRA2124E
Brand: PANASONIC
SKU: 140189994-0000-0000-0000

DRA2124E - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DRA2124E の詳細情報

型番	DRA2124E
メーカー	PANASONIC
カテゴリ	その他-トランジスタ
データシート
Additional Feature	BUILT IN BIAS RESISTOR RATIO IS 1
Collector Current-Max (IC)	0.1 A
Collector-emitter Voltage-Max	50 V
Configuration	SINGLE WITH BUILT-IN RESISTOR
DC Current Gain-Min (hFE)	60
JEDEC-95 Code	TO-236AA
JESD-30 Code	R-PDSO-G3
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Polarity/Channel Type	PNP
Power Dissipation-Max (Abs)	0.2 W
Qualification Status	Not Qualified
Sub Category	BIP General Purpose Small Signal
Surface Mount	YES
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	SWITCHING
Transistor Element Material	SILICON
