DB3X314F0L データシート

Name: DB3X314F0L
Brand: PANASONIC
SKU: 140145997-0000-0000-0000

DB3X314F0L - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DB3X314F0L の詳細情報

型番	DB3X314F0L
メーカー	PANASONIC
データシート
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode Element Material	SILICON
Diode Type	MIXER DIODE
Forward Voltage-Max (VF)	0.4 V
Frequency Band	L BAND
JEDEC-95 Code	TO-236AA
JESD-30 Code	R-PDSO-G3
Moisture Sensitivity Level	1
Number of Elements	2
Number of Terminals	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.03 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Rep Pk Reverse Voltage-Max	30 V
Sub Category	Rectifier Diodes
Surface Mount	YES
Technology	SCHOTTKY
Terminal Form	GULL WING
Terminal Position	DUAL
