DB2X41400L データシート

Name: DB2X41400L
Brand: PANASONIC
SKU: 140146130-0000-0000-0000

DB2X41400L - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DB2X41400L の詳細情報

型番	DB2X41400L
メーカー	PANASONIC
データシート
Application	GENERAL PURPOSE
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	0.49 V
JESD-30 Code	R-PDSO-F2
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	15 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	2 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Rep Pk Reverse Voltage-Max	40 V
Reverse Current-Max	200 uA
Reverse Recovery Time-Max	0.03 us
Surface Mount	YES
Technology	SCHOTTKY
Terminal Form	FLAT
Terminal Position	DUAL
