DA3S101F0L データシート

Name: DA3S101F0L
Brand: PANASONIC
SKU: 140145977-0000-0000-0000

DA3S101F0L - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DA3S101F0L の詳細情報

型番	DA3S101F0L
メーカー	PANASONIC
データシート
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode Capacitance-Max	1.2 pF
Diode Element Material	SILICON
Diode Type	MIXER DIODE
Frequency Band	VERY HIGH FREQUENCY
JESD-30 Code	R-PDSO-F3
JESD-609 Code	e1
Moisture Sensitivity Level	1
Number of Elements	2
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Surface Mount	YES
Terminal Finish	Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
Terminal Form	FLAT
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	10
