DA2J10100L データシート

Name: DA2J10100L
Brand: PANASONIC
SKU: 140131756-0000-0000-0000

DA2J10100L - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

DA2J10100L の詳細情報

型番	DA2J10100L
メーカー	PANASONIC
データシート
Configuration	SINGLE
Diode Capacitance-Max	1.2 pF
Diode Element Material	SILICON
Diode Type	MIXER DIODE
Frequency Band	VERY HIGH FREQUENCY
JESD-30 Code	R-PDSO-F2
JESD-609 Code	e3
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Surface Mount	YES
Terminal Finish	TIN
Terminal Form	FLAT
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	10
