AXK6S00435P の詳細情報

型番	AXK6S00435P
メーカー	PANASONIC
データシート
Additional Feature	LOW PROFILE
Board Mounting Option	POSITIONING PIN
Body Breadth	0.165 inch
Body Depth	0.13 inch
Body Length	1.11 inch
Body/Shell Style	PLUG
Connector Type	BOARD STACKING CONNECTOR
Contact Finish - Mating	GOLD OVER NICKEL
Contact Finish - Termination	GOLD
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	60 mohm
Contact Style	BELLOWED TYPE
DIN Conformance	NO
Dielectric Withstanding Voltage	150VAC V
Durability	50 Cycles
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	.7784 N
Insulation Resistance	1000000000 ohm
Insulator Material	POLYETHYLENE
JESD-609 Code	e4
MIL Conformance	NO
Manufacturer Series	P5
Mating Contact Pitch	0.02 inch
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	3.9878 mm
Polarization Key	D-SHAPE
Rated Current (Signal)	0.2 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.5 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	100
UL Flammability Code	94V-0
Withdrawl Force-Min	.0556 N
