AXK5F30547YG データシート

Name: AXK5F30547YG
Brand: PANASONIC
SKU: 110188987-0000-0000-0000

AXK5F30547YG - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

AXK5F30547YG の詳細情報

型番	AXK5F30547YG
メーカー	PANASONIC
データシート
Additional Feature	LOW PROFILE
Body Breadth	0.098 inch
Body Depth	0.053 inch
Body Length	0.413 inch
Body/Shell Style	SOCKET
Connector Type	BOARD STACKING CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	Gold (Au) - with Nickel (Ni) barrier
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	90 mohm
Contact Style	COMPRESSION
DIN Conformance	NO
Dielectric Withstanding Voltage	150VAC V
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	0.981 N
Insulation Resistance	1000000000 ohm
Insulator Material	LIQUID CRYSTAL POLYMER
JESD-609 Code	e4
MIL Conformance	NO
Mating Contact Pitch	0.0197 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	5.4 mm
Rated Current (Signal)	0.5 A
Reference Standard	UL
Terminal Pitch	0.5 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	30
UL Flammability Code	94V-0
Withdrawl Force-Min	0.0588 N
