AQY214EH データシート

Name: AQY214EH
Brand: PANASONIC
SKU: 110048690-0000-0000-0000

AQY214EH - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

AQY214EH の詳細情報

型番	AQY214EH
メーカー	PANASONIC
データシート
Additional Feature	HIGH SENSITIVITY, UL RECOGNIZED
Configuration	SINGLE
Control Current	0.0012 A
Control Voltage	1.14 V
Forward Current-Max	0.05 A
Input Type	DC
Isolation Voltage-Max	5000 V
JESD-609 Code	e0
Number of Elements	1
On-State Current-Max	0.12 A
On-state Resistance-Max	35 ohm
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Optoelectronic Device Type	TRANSISTOR OUTPUT SSR
Output Circuit Type	MOSFET
Overall Height	2.9 mm
Overall Length	4.78 mm
Packing Method	TR
Sub Category	Solid State Relays
Terminal Finish	Matte Tin (Sn)
