AN7818 の詳細情報

型番	AN7818
メーカー	PANASONIC
データシート
Adjustability	FIXED
Dropout Voltage1-Nom	2 V
Input Voltage Absolute-Max	35 V
Input Voltage-Max	33 V
Input Voltage-Min	21 V
JESD-30 Code	R-PSFM-T3
JESD-609 Code	e0
Length	6.5 mm
Line Regulation-Max	0.36 %
Load Regulation-Max	0.36 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	2
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	0 Cel
Output Current1-Max	1 A
Output Voltage1-Max	18.9 V
Output Voltage1-Min	17.1 V
Output Voltage1-Nom	18 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-252
Package Equivalence Code	SIP3,.1ISO-TB
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Seated Height-Max	2.6 mm
Sub Category	Other Regulators
Surface Mount	NO
Technology	BIPOLAR
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	2.3 mm
Terminal Position	SINGLE
Voltage Tolerance-Max	5 %
Width	5.5 mm
