AHN22224N データシート

Name: AHN22224N
Brand: PANASONIC
SKU: 110269190-0000-0000-0000

AHN22224N - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

AHN22224N の詳細情報

型番	AHN22224N
メーカー	PANASONIC
データシート
Body Breadth	13 inch
Body Height	28 mm
Body Length or Diameter	29 mm
Coil Operate Voltage(DC)	16.8 V
Coil Release Voltage(DC)	3.6 V
Coil Resistance	1090 ohm
Coil Voltage(DC)-Max	40.8 V
Coil Voltage-Nom	24 V
Coil/Input Supply Type	DC
Contact AC Max Power Rating R Load	1250VA@250VAC
Contact AC Max Rating R Load	5A@250VAC
Contact Current(AC)-Max	5 A
Contact Current(DC)-Max	5 A
Contact DC Max Power Rating R Load	150W@30VDC
Contact DC Max Rating R Load	5A@30VDC
Contact Resistance	50 mohm
Contact Voltage(AC)-Max	250 V
Contact Voltage(DC)-Max	30 V
Contact/Output Supply Type	AC/DC
Dielectric Strength Between Coil and Contacts	5000 Vrms
Dielectric Strength Between Open Contacts	1000 Vrms
Electrical Life	100000 Cycle(s)
End Contact Material	Silver Nickel
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Manufacturer Series	AHN
Number of Terminals	8
Operate Time	15 ms
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
Physical Dimension	29mm x 13mm x 28mm
Reference Standard	UL; VDE
Relay Action	LATCHED
Relay Form	2 FORM C
Relay Function	DPDT
Relay Type	POWER/SIGNAL RELAY
Release Time	5 ms
Terminal Length	0.006 inch
Termination Type	QUICK CONNECT
Weight	17 g
