ADP51A11 データシート

Name: ADP51A11
Brand: PANASONIC
SKU: 110239483-0000-0000-0000

ADP51A11 - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

ADP51A11 の詳細情報

型番	ADP51A11
メーカー	PANASONIC
データシート
Accuracy-Max (%)	4 %
Additional Feature	TEMPERATURE COMPENSATED
Body Breadth	7 inch
Body Height	3.5 mm
Body Length or Diameter	7.2 mm
Mounting Feature	THROUGH HOLE MOUNT
Offset-Nom	0.3V
Operating Current-Max	3 mA
Operating Temperature-Max	45 Cel
Operating Temperature-Min	5 Cel
Output Range	0.3-2.7V
Output Type	ANALOG VOLTAGE
Package Shape/Style	RECTANGULAR
Port Type	STRAIGHT
Pressure Range-Max	5.8 Psi
Pressure Sensing Mode	GAGE
Sensors/Transducers Type	PRESSURE SENSOR,STRAIN GUAGE
Supply Voltage-Max	3.15 V
Supply Voltage-Min	2.85 V
Termination Type	SOLDER
