10SVP10M データシート

Name: 10SVP10M
Brand: PANASONIC
SKU: 20498207-0000-0000-0000

10SVP10M - PANASONIC の商品詳細ページです。

２営業日以内に回答いたします

定格電圧 : V.DC 10

10SVP10M の詳細情報

型番	10SVP10M
メーカー	PANASONIC
データシート
Additional Feature	ESR IS MEASURED AT 100KHZ TO 300KHZ
Capacitance	10 uF
Capacitor Type	ALUMINUM ELECTROLYTIC CAPACITOR
Diameter	4 mm
Dielectric Material	ALUMINUM (SOLID POLYMER)
ESR	220 mohm
Height	5.4 mm
Leakage Current	.05 mA
Length	4.3 mm
Manufacturer Series	SVP
Mounting Feature	SURFACE MOUNT
Negative Tolerance	20 %
Number of Terminals	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Package Shape	CYLINDRICAL PACKAGE
Package Style	SMT Meter
Packing Method	TR
Polarity	POLARIZED
Positive Tolerance	20 %
Rated DC Voltage (URdc)	10 V
Ripple Current	35 mA
Size Code	1717
Tan Delta	0.1
Terminal Shape	FLAT
Width	4.3 mm
