XG5M-1632-N の詳細情報

型番	XG5M-1632-N
メーカー	OMRON
データシート
Additional Feature	POLARISED
Body Breadth	0.24 inch
Body Depth	0.567 inch
Body Length	0.98 inch
Body/Shell Style	SOCKET
Connector Type	BOARD CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	GOLD (6) OVER NICKEL
Contact Finish - Termination	TIN LEAD (78) OVER NICKEL
Contact Gender	FEMALE
Contact Material	PHOSPHOR BRONZE
Contact Pattern	RECTANGULAR
Contact Resistance	20 mohm
Contact Style	IDC
DIN Conformance	NO
Dielectric Withstanding Voltage	650VAC V
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	1.946 N
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
MIL Conformance	NO
Manufacturer Series	XG5M
Mating Contact Pitch	0.1 inch
Mating Contact Row Spacing	0.1 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Type	CABLE
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Plating Thickness	6u inch
Rated Current (Signal)	3 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	D Type Connectors
Termination Type	IDC
Total Number of Contacts	16
UL Flammability Code	94V-0
Wire Size-Max	24 AWG
Wire Size-Min	24 AWG
Withdrawl Force-Min	.278 N
