G6D-1A-ASI DC24 データシート

Name: G6D-1A-ASI DC24
Brand: OMRON
SKU: 170015710-0000-0000-0000

G6D-1A-ASI DC24 - OMRON の商品詳細ページです。

２営業日以内に回答いたします

G6D-1A-ASI DC24 の詳細情報

型番	G6D-1A-ASI DC24
メーカー	OMRON
データシート
Body Breadth	6.5 inch
Body Height	12.5 mm
Body Length or Diameter	17.5 mm
Coil Current(DC)-Max	0.008 A
Coil Operate Voltage(DC)	16.8 V
Coil Power	200 mW
Coil Release Voltage(DC)	2.4 V
Coil Resistance	2880 ohm
Coil Voltage(DC)-Max	24 V
Coil Voltage-Nom	24 V
Coil/Input Supply Type	DC
Contact AC Max Rating R Load	5A@250VAC
Contact Current(AC)-Max	5 A
Contact Current(DC)-Max	5 A
Contact DC Max Rating R Load	5A@30VDC
Contact Resistance	100 mohm
Contact Voltage(AC)-Max	250 V
Contact Voltage(DC)-Max	30 V
Contact/Output Supply Type	AC/DC
Dielectric Strength Between Coil and Contacts	3000 Vrms
Dielectric Strength Between Open Contacts	750 Vrms
Electrical Life	70000 Cycle(s)
End Contact Material	Silver Alloy
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Mounting Feature	THROUGH HOLE-STRAIGHT MOUNT
Number of Terminals	4
Operate Time	10 ms
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-25 Cel
PCB Hole Count	4
Physical Dimension	17.5mm x 6.5mm x 12.5mm
Reference Standard	CSA; EN; TUV; UL
Relay Action	MOMENTARY
Relay Form	1 FORM A
Relay Function	SPST
Relay Type	POWER/SIGNAL RELAY
Release Time	5 ms
Terminal Length	0.0035 inch
Termination Type	SOLDER
Weight	3 g
