G5B-1 DC12

Name: G5B-1 DC12
Brand: OMRON
SKU: 170014287-0000-0000-0000

G5B-1 DC12 - OMRON の商品詳細ページです。

２営業日以内に回答いたします

G5B-1 DC12 の詳細情報

型番	G5B-1 DC12
メーカー	OMRON
Body Breadth	11.5 inch
Body Height	14 mm
Body Length or Diameter	22 mm
Coil Operate Voltage(DC)	8.4 V
Coil Release Voltage(DC)	0.6 V
Coil Resistance	400 ohm
Coil Voltage(DC)-Max	13.2 V
Coil Voltage-Nom	12 V
Coil/Input Supply Type	DC
Contact AC Max Power Rating R Load	750VA@125VAC
Contact AC Max Rating R Load	3A@125VAC
Contact Current(AC)-Max	3 A
Contact Current(DC)-Max	3 A
Contact DC Max Power Rating R Load	90W@30VDC
Contact DC Max Rating R Load	3A@30VDC
Contact Resistance	100 mohm
Contact Voltage(AC)-Max	125 V
Contact Voltage(DC)-Max	30 V
Contact/Output Supply Type	AC/DC
Dielectric Strength Between Coil and Contacts	4000 Vrms
Dielectric Strength Between Open Contacts	1000 Vrms
End Contact Material	Silver
Input Switching Control Type	Random
Insulation Resistance	1000000000 ohm
Number of Terminals	4
Operate Time	10 ms
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
PCB Hole Count	4
Physical Dimension	22mm x 11.5mm x 14mm
Reference Standard	CSA; UL
Relay Form	1 FORM A
Relay Function	SPST
Release Time	10 ms
Terminal Length	0.0035 inch
Termination Type	SOLDER
Weight	7 g
