ML4812IP

Name: ML4812IP
Brand: MICROLINEAR
SKU: 230725598-0000-0000-0000

ML4812IP - MICROLINEAR の商品詳細ページです。

２営業日以内に回答いたします

ML4812IP の詳細情報

型番	ML4812IP
メーカー	MICROLINEAR
Analog IC - Other Type	POWER FACTOR CONTROLLER
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	25 V
Input Voltage-Min	11 V
Input Voltage-Nom	15 V
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Length	19.05 mm
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	1 A
Output Voltage-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Qualification Status	Not Qualified
Seated Height-Max	4.32 mm
Sub Category	Switching Regulator or Controllers
Supply Current-Max (Isup)	25 mA
Surface Mount	NO
Switcher Configuration	SINGLE
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Width	7.62 mm
