SMAJ4736A-TP
1
-
- 個
２営業日以内に回答いたします
SMAJ4736A-TP の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | SMAJ4736A-TP |
|---|---|
| メーカー | MICRO COMMERCIAL |
| Additional Feature | LOW IMPEDANCE |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | ZENER DIODE |
| Dynamic Impedance-Max | 3.5 ohm |
| JEDEC-95 Code | DO-214AC |
| JESD-30 Code | R-PDSO-C2 |
| JESD-609 Code | e3 |
| Knee Impedance-Max | 700 ohm |
| Moisture Sensitivity Level | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 150 Cel |
| Operating Temperature-Min | -65 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Polarity | UNIDIRECTIONAL |
| Power Dissipation-Max | 1 W |
| Qualification Status | Not Qualified |
| Reference Voltage-Nom | 6.8 V |
| Reverse Current-Max | 0.01 uA |
| Sub Category | Voltage Reference Diodes |
| Surface Mount | YES |
| Technology | ZENER |
| Terminal Finish | MATTE TIN |
| Terminal Form | C BEND |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 10 |
| Voltage Tol-Max | 5 % |
| Working Test Current | 37 mA |
| 会社名称 | Micro Commercial Components Corp. |
|---|---|
| 設立 | 1991 |
| 所在地 | 20736 Marilla Street Chatsworth, CA91311, USA |
| URL | http://www.mccsemi.com/ |
