GS1G-TP の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | GS1G-TP |
|---|---|
| メーカー | MICRO COMMERCIAL |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | RECTIFIER DIODE |
| Forward Voltage-Max (VF) | 1.1 V |
| JEDEC-95 Code | DO-214AC |
| JESD-30 Code | R-PDSO-C2 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | 1 |
| Non-rep Pk Forward Current-Max | 30 A |
| Number of Elements | 1 |
| Number of Phases | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 150 Cel |
| Operating Temperature-Min | -55 Cel |
| Output Current-Max | 1 A |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 240 |
| Qualification Status | Not Qualified |
| Rep Pk Reverse Voltage-Max | 400 V |
| Reverse Current-Max | 10 uA |
| Surface Mount | YES |
| Terminal Finish | MATTE TIN |
| Terminal Form | C BEND |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 10 |
| 会社名称 | Micro Commercial Components Corp. |
|---|---|
| 設立 | 1991 |
| 所在地 | 20736 Marilla Street Chatsworth, CA91311, USA |
| URL | http://www.mccsemi.com/ |
