DL4745A
1
-
- 個
２営業日以内に回答いたします
DL4745A の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | DL4745A |
|---|---|
| メーカー | MICRO COMMERCIAL |
| Additional Feature | HIGH RELIABILITY |
| Case Connection | ISOLATED |
| Configuration | SINGLE |
| DLA Qualification | Not Qualified |
| Diode Element Material | SILICON |
| Diode Type | ZENER DIODE |
| Dynamic Impedance-Max | 16 ohm |
| Dynamic Impedance-Max (ohm) | 16 |
| JESD-30 Code | O-LELF-R2 |
| JESD-609 Code | e0 |
| Knee Impedance-Max | 700 ohm |
| Moisture Sensitivity Level | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 175 Cel |
| Operating Temperature-Max (Cel) | 200 |
| Operating Temperature-Min | -65 Cel |
| Package Body Material | GLASS |
| Package Shape | ROUND |
| Package Style | LONG FORM Meter |
| Peak Reflow Temperature (Cel) | 240 |
| Polarity | UNIDIRECTIONAL |
| Power Dissipation-Max | 0.5 W |
| Power Dissipation-Max (W) | 1 |
| Qualification Status | Not Qualified |
| Reference Voltage-Nom | 16 V |
| Reference Voltage-Nom (V) | 16 |
| Reverse Current-Max | 0.005 uA |
| Reverse Test Voltage | 12.2 V |
| Sub Category | Voltage Reference Diodes |
| Surface Mount | YES |
| Technology | ZENER |
| Terminal Finish | MATTE TIN |
| Terminal Form | WRAP AROUND |
| Terminal Position | END |
| Time@Peak Reflow Temperature-Max (s) | 10 |
| Voltage Tol-Max | 5 % |
| Voltage Tolerance-Max (%) | 5 |
| Working Test Current | 15 mA |
| Working Test Current (mA) | 15.5 |
| 会社名称 | Micro Commercial Components Corp. |
|---|---|
| 設立 | 1991 |
| 所在地 | 20736 Marilla Street Chatsworth, CA91311, USA |
| URL | http://www.mccsemi.com/ |
