TC4421AVPA データシート

Name: TC4421AVPA
Brand: MICROCHIP
SKU: 300226588-0000-0000-0000

TC4421AVPA - MICROCHIP の商品詳細ページです。

２営業日以内に回答いたします

TC4421AVPA の詳細情報

型番	TC4421AVPA
メーカー	MICROCHIP
データシート
High Side Driver	YES
Input Characteristics	SCHMITT TRIGGER
Interface IC Type	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e3
Length	9.46 mm
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	TOTEM-POLE
Output Peak Current Limit-Nom	10 A
Output Polarity	INVERTED
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Power Supplies	4.5/18 V
Qualification Status	Not Qualified
Screening Level	TS 16949
Seated Height-Max	4.32 mm
Sub Category	MOSFET Drivers
Supply Current-Max	0.5 mA
Supply Voltage-Max	18 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	12 V
Supply Voltage1-Max	18 V
Supply Voltage1-Min	4.5 V
Supply Voltage1-Nom	12 V
Surface Mount	NO
Temperature Grade	AUTOMOTIVE
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Turn-off Time	0.105 us
Turn-on Time	0.1 us
Width	7.62 mm
