TC1044SEOA の詳細情報

型番	TC1044SEOA
メーカー	MICROCHIP
データシート
Analog IC - Other Type	SWITCHED CAPACITOR CONVERTER
DLA Qualification	Not Qualified
Input Voltage-Max	12 V
Input Voltage-Max (V)	12
Input Voltage-Min	1.5 V
Input Voltage-Min (V)	1.5
Input Voltage-Nom	5 V
Input Voltage-Nom (V)	5
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e0
Length	4.9 mm
Length (mm)	4.9
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Output Current-Max	0.02 A
Output Voltage-Max	-12 V
Output Voltage-Max (V)	-12
Output Voltage-Min	-1.5 V
Output Voltage-Min (V)	-1.5
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Seated Height-Max (mm)	1.75
Sub Category	Other Analog ICs
Supply Current-Max (Isup)	0.18 mA
Supply Current-Max (mA)	0.18
Surface Mount	YES
Switcher Configuration	DOUBLER INVERTER
Switching Frequency-Max	45 kHz
Switching Frequency-Max (kHz)	45
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Pitch (mm)	1.27
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	3.9 mm
