SST25VF064C-80-4I-S3AE

Name: SST25VF064C-80-4I-S3AE
Brand: MICROCHIP
SKU: 400065358-0000-0000-0000

SST25VF064C-80-4I-S3AE - MICROCHIP の商品詳細ページです。

２営業日以内に回答いたします

SST25VF064C-80-4I-S3AE の詳細情報

型番	SST25VF064C-80-4I-S3AE
メーカー	MICROCHIP
Clock Frequency-Max (MHz)	80
Clock Frequency-Max (fCLK)	80 MHz
DLA Qualification	Not Qualified
Endurance (Write/Erase Cycles)	100000
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
Length	7.21 mm
Length (mm)	7.21
Memory Density	64094208 bit
Memory Density (bits)	64094208
Memory IC Type	FLASH
Memory Organization	8MX8
Memory Width	1
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Number of Words	64094208 words
Number of Words (words)	8388608
Number of Words Code	8M
Operating Mode	SYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Organization	64MX1
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Parallel/Serial	SERIAL
Power Supplies (V)	3/3.3
Programming Voltage	2.7 V
Programming Voltage (V)	2.7
Qualification Status	Not Qualified
Seated Height-Max	2.16 mm
Seated Height-Max (mm)	2.16
Serial Bus Type	SPI
Standby Current-Max (A)	2.0E-5
Sub Category	Flash Memories
Supply Current-Max (mA)	25
Supply Voltage-Max (V)	3.6
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch (mm)	1.27
Terminal Position	DUAL
Type	NOR TYPE
Write Protection	HARDWARE/SOFTWARE
