PIC16C58A-20/SO データシート Microchip

PIC16C58A-20/SO - MICROCHIP の商品詳細ページです。

1
PIC16C58A-20/SO
  • PIC16C58A-20/SO
  • PIC16C58A-20/SO
  • PIC16C58A-20/SO
  • PIC16C58A-20/SO
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

PIC16C58A-20/SO の詳細情報

  • 仕様・詳細
  • メーカー情報
型番PIC16C58A-20/SO
メーカーMICROCHIP
データシートProduct_list_pdf
ADC Channels NO
Address Bus Width 0
Bit Size 8
CPU Family PIC
Clock Frequency-Max 4 MHz
DAC Channels NO
DMA Channels NO
Data EEPROM Size 0
External Data Bus Width 0
JESD-30 Code R-PDSO-G18
JESD-609 Code e0
Length 11.58 mm
Number of I/O Lines 12
Number of Terminals 18
On Chip Program ROM Width 12
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
PWM Channels NO
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP18,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Peripherals POR, TIMER, WDT
Power Supplies 3.3/5 V
Qualification Status Not Qualified
RAM (bytes) 73
ROM (words) 2048
ROM Programmability OTPROM
Seated Height-Max 2.64 mm
Speed 5 rpm
Sub Category Microcontrollers
Supply Current-Max 17 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 2.5 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Width 7.51 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
会社名称Microchip Technology Inc.
所在地2355 West Chandler Blvd. Chandler, Arizona, USA 85224-6199
URLhttp://www.microchip.com/
