PIC12F629-I/SN-G データシート Microchip

PIC12F629-I/SN-G - MICROCHIP の商品詳細ページです。

1
No Image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

PIC12F629-I/SN-G の詳細情報

  • 仕様・詳細
  • メーカー情報
型番PIC12F629-I/SN-G
メーカーMICROCHIP
データシートProduct_list_pdf
ADC Channels NO
Additional Feature CAN ALSO OPERATE AT 4MHZ AT 2VMIN SUPPLY AND 10MHZ AT 3V MIN SUPPLY
Address Bus Width 0
Bit Size 8
Boundary Scan NO
CPU Family PIC
Clock Frequency-Max (MHz) 20
DAC Channels NO
DLA Qualification Not Qualified
DMA Channels NO
Data EEPROM Size (bytes) 128
Data RAM Size (bytes) 64
External Data Bus Width 0
Format FLOATING POINT
Integrated Cache NO
J-STD-609 Code e3
JESD-30 Code R-PDSO-G8
Length (mm) 4.9
Low Power Mode NO
Moisture Sensitivity Level 1
Number of External Interrupts 1
Number of I/O Lines 6
Number of Terminals 8
Number of Timers 2
On Chip Data RAM Width 8
Operating Temperature-Max (Cel) 85
Operating Temperature-Min (Cel) -40
PWM Channels NO
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP8,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Peak Reflow Temperature (Cel) 260
Peripherals BOD, COMPARATOR, POR, TIMER(2), WDT
Program Memory Size (words) 1024
Program Memory Type FLASH
Program Memory Width (bits) 14
Screening Level / Reference Standard TS 16949
Seated Height-Max (mm) 1.75
Speed (MHz) 20
Supply Current-Max (mA) 3
Supply Voltage-Max (V) 5.5
Supply Voltage-Min (V) 4.5
Supply Voltage-Nom (V) 5
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
会社名称Microchip Technology Inc.
所在地2355 West Chandler Blvd. Chandler, Arizona, USA 85224-6199
URLhttp://www.microchip.com/
