MCP6021T-E/OT

Name: MCP6021T-E/OT
Brand: MICROCHIP
SKU: 400048026-0000-0000-0000

MCP6021T-E/OT - MICROCHIP の商品詳細ページです。

２営業日以内に回答いたします

MCP6021T-E/OT の詳細情報

型番	MCP6021T-E/OT
メーカー	MICROCHIP
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	0.005 uA
Common-mode Reject Ratio-Min	74 dB
Common-mode Reject Ratio-Nom	90 dB
Frequency Compensation	YES
Input Offset Voltage-Max	2500 uV
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e3
Length	2.95 mm
Low-Bias	YES
Low-Offset	NO
Micropower	NO
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	5
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TSOP5/6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power	NO
Power Supplies	3/5 V
Programmable Power	NO
Qualification Status	Not Qualified
Screening Level	AEC-Q100; TS 16949
Seated Height-Max	1.45 mm
Slew Rate-Nom	7 V/us
Sub Category	Operational Amplifier
Supply Current-Max	1.35 mA
Supply Voltage Limit-Max	7 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Unity Gain BW-Nom	10000 kHz
Voltage Gain-Min	31620
Wideband	NO
Width	1.63 mm
