MCP1726-1802E/MF データシート

Name: MCP1726-1802E/MF
Brand: MICROCHIP
SKU: 230532232-0000-0000-0000

MCP1726-1802E/MF - MICROCHIP の商品詳細ページです。

２営業日以内に回答いたします

MCP1726-1802E/MF の詳細情報

型番	MCP1726-1802E/MF
メーカー	MICROCHIP
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.5 V
Dropout Voltage1-Nom	0.22 V
Input Voltage Absolute-Max	6.5 V
Input Voltage-Max	6 V
Input Voltage-Min	2.3 V
JESD-30 Code	S-PDSO-N8
JESD-609 Code	e3
Length	3 mm
Line Regulation-Max	0.01998 %
Load Regulation-Max	0.027 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	1 A
Output Voltage1-Max	1.845 V
Output Voltage1-Min	1.755 V
Output Voltage1-Nom	1.8 V
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Equivalence Code	SOLCC8,.11,25
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Packing Method	TUBE
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Screening Level	TS 16949
Seated Height-Max	1 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	CMOS
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Form	NO LEAD
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Voltage Tolerance-Max	2.5 %
Width	3 mm
