LAN8710AI-EZK
1
-
- 個
２営業日以内に回答いたします
LAN8710AI-EZK の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | LAN8710AI-EZK |
|---|---|
| メーカー | MICROCHIP |
| DLA Qualification | Not Qualified |
| Data Rate (Mbps) | 100 |
| J-STD-609 Code | e3 |
| JESD-30 Code | S-XQCC-N32 |
| Length (mm) | 5 |
| Moisture Sensitivity Level | 3 |
| Number of Functions | 1 |
| Number of Terminals | 32 |
| Number of Transceivers | 1 |
| Operating Temperature-Max (Cel) | 85 |
| Operating Temperature-Min (Cel) | -40 |
| Package Body Material | UNSPECIFIED |
| Package Code | HVQCCN |
| Package Equivalence Code | LCC32,.2SQ,20 |
| Package Shape | SQUARE |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies (V) | 3.3 |
| Screening Level / Reference Standard | TS 16949 |
| Seated Height-Max (mm) | 1 |
| Sub Category | Network Interfaces |
| Supply Voltage-Nom (V) | 1.2 |
| Surface Mount | YES |
| Technology | CMOS |
| Telecom IC Type | ETHERNET TRANSCEIVER |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | NO LEAD |
| Terminal Pitch (mm) | 0.5 |
| Terminal Position | QUAD |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Width (mm) | 5 |
| 会社名称 | Microchip Technology Inc. |
|---|---|
| 所在地 | 2355 West Chandler Blvd. Chandler, Arizona, USA 85224-6199 |
| URL | http://www.microchip.com/ |
