AT17LV010A-10PU
1
-
- 個
２営業日以内に回答いたします
AT17LV010A-10PU の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | AT17LV010A-10PU |
|---|---|
| メーカー | MICROCHIP |
| Additional Feature | ALSO OPERATES AT 5V SUPPLY |
| Clock Frequency-Max (MHz) | 15 |
| DLA Qualification | Not Qualified |
| J-STD-609 Code | e3 |
| JESD-30 Code | R-PDIP-T8 |
| Length (mm) | 9.271 |
| Memory Density (bits) | 1048576 |
| Memory IC Type | CONFIGURATION MEMORY |
| Memory Organization | 1MX1 |
| Memory Width | 1 |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Number of Words (words) | 1048576 |
| Number of Words Code | 1M |
| Operating Mode | SYNCHRONOUS |
| Operating Temperature-Max (Cel) | 85 |
| Operating Temperature-Min (Cel) | -40 |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP8,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Parallel/Serial | SERIAL |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies (V) | 3.3/5 |
| Seated Height-Max (mm) | 5.334 |
| Sub Category | EEPROMs |
| Supply Current-Max (mA) | 10 |
| Supply Voltage-Max (V) | 3.6 |
| Supply Voltage-Min (V) | 3 |
| Supply Voltage-Nom (V) | 3.3 |
| Surface Mount | NO |
| Technology | CMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch (mm) | 2.54 |
| Terminal Position | DUAL |
| Width (mm) | 7.62 |
| Write Protection | HARDWARE |
| 会社名称 | Microchip Technology Inc. |
|---|---|
| 所在地 | 2355 West Chandler Blvd. Chandler, Arizona, USA 85224-6199 |
| URL | http://www.microchip.com/ |
