93LC66B-I/SN

Name: 93LC66B-I/SN
Brand: MICROCHIP
SKU: 100109188-0000-0000-0000

93LC66B-I/SN - MICROCHIP の商品詳細ページです。

２営業日以内に回答いたします

93LC66B-I/SN の詳細情報

型番	93LC66B-I/SN
メーカー	MICROCHIP
Additional Feature	1000000 ERASE/WRITE CYCLES MIN; DATA RETENTION > 200 YEARS
Clock Frequency-Max (MHz)	1
DLA Qualification	Not Qualified
Data Retention Time-Min	200
Endurance (Write/Erase Cycles)	1000000
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
Length (mm)	4.9
Memory Density (bits)	4096
Memory IC Type	EEPROM
Memory Organization	256X16
Memory Width	16
Moisture Sensitivity Level	1
Number of Functions	1
Number of Ports	1
Number of Terminals	8
Number of Words (words)	256
Number of Words Code	256
Operating Mode	SYNCHRONOUS
Operating Temperature-Max (Cel)	85
Operating Temperature-Min (Cel)	-40
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Parallel/Serial	SERIAL
Peak Reflow Temperature (Cel)	260
Power Supplies (V)	3/5
Ready/Busy	YES
Reverse Pinout	NO
Screening Level / Reference Standard	AEC-Q100
Seated Height-Max (mm)	1.75
Serial Bus Type	MICROWIRE
Standby Current-Max (A)	1.0E-6
Sub Category	EEPROMs
Supply Current-Max (mA)	2
Supply Voltage-Max (V)	5.5
Supply Voltage-Min (V)	1.8
Supply Voltage-Nom (V)	2.5
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch (mm)	1.27
Terminal Position	DUAL
Width (mm)	3.9
Write Cycle Time-Max (tWC) (ms)	6
