25AA040AT-I/OT データシート

Name: 25AA040AT-I/OT
Brand: MICROCHIP
SKU: 30103552-0000-0000-0000

25AA040AT-I/OT - MICROCHIP の商品詳細ページです。

No Image

２営業日以内に回答いたします

25AA040AT-I/OT の詳細情報

型番	25AA040AT-I/OT
メーカー	MICROCHIP
データシート
Clock Frequency-Max (MHz)	10
DLA Qualification	Not Qualified
Data Retention Time-Min	200
Endurance (Write/Erase Cycles)	1000000
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e3
Length (mm)	2.9
Memory Density (bits)	4096
Memory IC Type	EEPROM
Memory Organization	512X8
Memory Width	8
Moisture Sensitivity Level	1
Number of Functions	1
Number of Ports	1
Number of Terminals	6
Number of Words (words)	512
Number of Words Code	512
Operating Mode	SYNCHRONOUS
Operating Temperature-Max (Cel)	85
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TSOP6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Parallel/Serial	SERIAL
Peak Reflow Temperature (Cel)	260
Power Supplies (V)	2/5
Programming Voltage (V)	2.5
Screening Level / Reference Standard	AEC-Q100
Seated Height-Max (mm)	1.45
Serial Bus Type	SPI
Standby Current-Max (A)	1.0E-6
Sub Category	EEPROMs
Supply Current-Max (mA)	5
Supply Voltage-Max (V)	5.5
Supply Voltage-Min (V)	1.8
Supply Voltage-Nom (V)	2.5
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch (mm)	0.95
Terminal Position	DUAL
Width (mm)	1.55
Write Cycle Time-Max (tWC) (ms)	5
Write Protection	HARDWARE/SOFTWARE
