MIC37502WR

Name: MIC37502WR
Brand: MICREL
SKU: 230761960-0000-0000-0000

MIC37502WR - MICREL の商品詳細ページです。

２営業日以内に回答いたします

MIC37502WR の詳細情報

型番	MIC37502WR
メーカー	MICREL
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	0.5 V
Dropout Voltage1-Nom	0.33 V
Input-Output Voltage Differential-Max	4.76 V
Input-Output Voltage Differential-Min	1 V
JESD-30 Code	R-PSSO-G7
JESD-609 Code	e3
Length	9.395 mm
Line Regulation-Max (%/V)	0.13
Load Regulation-Max(%)	1 %
Moisture Sensitivity Level	3
Number of Functions	1
Number of Outputs	1
Number of Terminals	7
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	5 A
Output Voltage1-Max	5.5 V
Output Voltage1-Min	1.24 V
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	SMSIP7H,.4,50TB
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	2.16 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	40
Width	8 mm
