MIC29150-3.3WT データシート

Name: MIC29150-3.3WT
Brand: MICREL
SKU: 230018157-0000-0000-0000

MIC29150-3.3WT - MICREL の商品詳細ページです。

２営業日以内に回答いたします

MIC29150-3.3WT の詳細情報

型番	MIC29150-3.3WT
メーカー	MICREL
データシート
Adjustability	FIXED
DLA Qualification	Not Qualified
Dropout Voltage1-Max	0.6 V
Dropout Voltage1-Max (V)	0.6
Dropout Voltage1-Nom	0.35 V
Dropout Voltage1-Nom (V)	0.35
Input Voltage Absolute-Max	60 V
Input Voltage Absolute-Max (V)	60
Input Voltage-Max	26 V
Input Voltage-Max (V)	26
Input Voltage-Min	4.3 V
Input Voltage-Min (V)	4.3
J-STD-609 Code	e3
JESD-30 Code	R-XSFM-T3
JESD-609 Code	e3
Line Regulation-Max	0.0165 %
Line Regulation-Max (V)	0.0165
Load Regulation-Max	0.033 %
Load Regulation-Max (V)	0.033
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature TJ-Max (Cel)	125
Operating Temperature TJ-Min (Cel)	-40
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	1.5 A
Output Current1-Max (A)	1.5
Output Voltage1-Max	3.366 V
Output Voltage1-Max (V)	3.366
Output Voltage1-Min	3.234 V
Output Voltage1-Min (V)	3.234
Output Voltage1-Nom	3.3 V
Output Voltage1-Nom (V)	3.3
Package Body Material	UNSPECIFIED
Package Code	TO-220
Package Equivalence Code	SIP3,.1TB
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Packing Method	TUBE
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Screening Level / Reference Standard	TS 16949
Sub Category	Other Regulators
Surface Mount	NO
Technology	BIPOLAR
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
Voltage Tolerance-Max	2 %
