MAX999EUK+T の詳細情報

  • 仕様・詳細
  • メーカー情報
型番MAX999EUK+T
メーカーMAXIM
データシートProduct_list_pdf
Amplifier Type COMPARATOR
Average Bias Current-Max (IIB) 30 uA
Average Bias Current-Max (IIB) (uA) 30
Bias Current-Max (IIB) @25C 15 uA
Bias Current-Max (IIB) @25C (uA) 15
DLA Qualification Not Qualified
Input Offset Voltage-Max 4500 uV
Input Offset Voltage-Max (uV) 4500
J-STD-609 Code e3
JESD-30 Code R-PDSO-G5
JESD-609 Code e3
Length 2.9 mm
Length (mm) 2.9
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 5
Operating Temperature-Max 85 Cel
Operating Temperature-Max (Cel) 85
Operating Temperature-Min -40 Cel
Operating Temperature-Min (Cel) -40
Package Body Material PLASTIC/EPOXY
Package Code LSSOP
Package Equivalence Code TSOP5/6,.11,37
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel) 260
Power Supplies 3/5 V
Power Supplies (V) 3/5
Qualification Status Not Qualified
Response Time-Nom 4.5 ns
Response Time-Nom (ns) 4.5
Seated Height-Max 1.45 mm
Seated Height-Max (mm) 1.45
Sub Category Comparator
Supply Current-Max 6.5 mA
Supply Current-Max (mA) 6.5
Supply Voltage Limit-Max 5.5 V
Supply Voltage Limit-Max (V) 5.5
Supply Voltage-Nom (V) 3
Supply Voltage-Nom (Vsup) 3 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.95 mm
Terminal Pitch (mm) 0.95
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 1.625 mm
会社名称Maxim Integrated Products, Inc.
設立1983
所在地160 Rio Robles San Jose, CA 95134 USA
URLhttp://www.maxim-ic.com/
