MAX9814ETD+T
データシート
1
-
- 個
２営業日以内に回答いたします
MAX9814ETD+T の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | MAX9814ETD+T |
|---|---|
| メーカー | MAXIM |
| データシート |  |
| Bandwidth-Nom (MHz) | 0.022 |
| Consumer IC Type | AUDIO AMPLIFIER |
| DLA Qualification | Not Qualified |
| Gain (dB) | 40 |
| J-STD-609 Code | e3 |
| JESD-30 Code | S-XDSO-N14 |
| Length (mm) | 3 |
| Moisture Sensitivity Level | 1 |
| Number of Channels | 1 |
| Number of Functions | 1 |
| Number of Terminals | 14 |
| Operating Temperature-Max (Cel) | 85 |
| Operating Temperature-Min (Cel) | -40 |
| Package Body Material | UNSPECIFIED |
| Package Code | HVSON |
| Package Equivalence Code | SOLCC14,.12,16 |
| Package Shape | SQUARE |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Seated Height-Max (mm) | 0.8 |
| Supply Current-Max (mA) | 6 |
| Supply Voltage-Max (V) | 5.5 |
| Supply Voltage-Min (V) | 2.7 |
| Surface Mount | YES |
| Technology | BICMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | NO LEAD |
| Terminal Pitch (mm) | 0.4 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width (mm) | 3 |
| 会社名称 | Maxim Integrated Products, Inc. |
|---|---|
| 設立 | 1983 |
| 所在地 | 160 Rio Robles San Jose, CA 95134 USA |
| URL | http://www.maxim-ic.com/ |
