MAX913CPA データシート

Name: MAX913CPA
Brand: MAXIM
SKU: 230007101-0000-0000-0000

MAX913CPA - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX913CPA の詳細情報

型番	MAX913CPA
メーカー	MAXIM
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	8 uA
Bias Current-Max (IIB) @25C	5 uA
Input Offset Voltage-Max	3000 uV
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e0
Length	9.375 mm
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-7 V
Neg Supply Voltage-Nom (Vsup)	-5 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5/+-5 V
Qualification Status	Not Qualified
Response Time-Nom	10 ns
Seated Height-Max	4.572 mm
Sub Category	Comparator
Supply Current-Max	10 mA
Supply Voltage Limit-Max	7 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	7.62 mm
